Troubleshooting

FTB-1v2 and FTB-1v2 Pro 343

Restoring Your Unit to Normal Operation

7. If you want to refresh or reset your unit, proceed as follows:

7a. Tap the Get started button corresponding to your choice.

7b. Follow the on-screen instructions.

8. If you want to restore your unit (with a WIM file), proceed as follows:

8a. Under Advanced Startup, tap Restart now.

To refresh your unit

To reset your unit
