Data Types

378 FTB-1v2 and FTB-1v2 Pro

Applicable Data Types for Output —IEEE 488.2

 <OCTAL NUMERIC RESPONSE DATA>

This data type will be used by a device to return integer representations

in octal (base 8).

Examples: #Q753214, #Q0124, #Q0725

# Q
