IEEE 488.2 and Specific Command Reference

410 FTB-1v2 and FTB-1v2 Pro

Specific Commands

When the data is returned in ASCII, the

<Length> is the number of significant digits to

be returned. A <Length> value of zero indicates

that the device selects the number of significant

digits to be returned.

When the data is returned in PACKED <Type>,

the <Length> is not used and always returns 0.

Example(s) FORM? returns ASCII,6

FORM? returns PACKED,0

See Also FORMat[:DATA]?

:FORMat[:DATA]?
