Setting Up Your Variable Attenuator
Variable Attenuator 31
Selecting and Using an Attenuation Display Mode
4. Press ENTER. The first segment of the current offset value will start
flashing.
5. Enter a new offset. Use the up/down arrows to change the flashing digit
and the left/right arrows to activate the next digit.
Note: Offset values between -99.999 and 99.999 may be entered. Use dB when
the offset represents loss and dBm when the offset represents power.
6. Once all the segments have been entered, press ENTER.
7. To exit the Setup menu, press the Setup button.
