Setting Up Your Variable Attenuator
Variable Attenuator 37
Saving and Recalling a Configuration
5. Press the up/down arrows to modify the configuration number.
6. Press ENTER.
7. Press on the Setup button to exit the menu.
Once you have saved a configuration (see Saving and Recalling a
Configuration on page 35), you can recall it at any time.
To recall a configuration:
1. Press on the Setup button.
VARIABLE ATTENUATOR
FVA-3100
Offset
ENTER
Abs Up Shutter
Ref
λ
Down Attenuation
Program
Setup
Confirmation
button
Arrow buttons for menu navigation
and parameter setting
Step
In Monitor Out
Setup menu access
Shutter
