ProductOverview
WheelBase:(CenterofDriveWheel
toCenterofRearCasterWheel)
42inchDeck48inchDeck
44.2inches(112.3cm)44.2inches(112.3cm)
CurbWeight:
42inchDeck48inchDeck
1140lb(517kg)1170lb(531kg)
TorqueRequirements
BoltLocation
Torque
BladeMountingBolt85-110ft-lb(115-149
N-m)
EngineMountingBolts
30-35ft-lb(41-47N-m)
WheelLugNuts
85-105ft-lb(122-129
N-m)
WheelMotorMounting
Bolts
72-77ft-lb(115-142N-m)
WheelHubLocknut275-350ft-lb
(373-475N-m)
BladeDriverShearBolts80-100in-lb
(922-1130N-cm)
ProductOverview
Figure4
1.SpeedControlLever4.SteeringLevers
2.Controls5.PTOEngagementLever
3.FuelCap
6.ParkingBrakeLever
19
