Exmark NAVIGATOR User Manual

Maintenance
Figure35
1.Alignthreepumpdrive
pulleysurfacesshown
withthispatternwithin
1/32inchto1/16inch
(0.8-1.6mm).
2.AlignthreePTOdrive
pulleysurfacesshown
withthispatternwithin
1/32inchto1/16inch
(0.8-1.6mm).
10.Tightenthefourenginemountingboltsandfour
jackshaftmountingbolts.Checkalignmentafter
tightening.
11.Re-installpumpbelttensionspring.
12.Swingfueltankinandre-installtankmounting
nuts.
13.CompletethePumpDrivePulleyAlignment
section.
PumpDrivePulleyAlignment
Pumpdrivepulleyalignmentisnecessaryforanyof
thefollowingconditions:
•Theenginemountingboltshavebeenloosenedor
theenginehasbeenmovedorreplaced.
•Thepumppulleyshavebeenloosened,moved,
orreplaced.
•ThePTOpulleyalignmenthasbeenperformed
(seePTODrivePulleyAlignmentsection).
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Loosensetscrewsonbothpumppulleys.
3.Usingastraightedge,aligneachpumppulleywith
theenginepulleybyslidingalongthepumpshaft
(seeFigure35).
4.Re-tightenpulleysetscrewsandrecheck
alignment.
CasterPivotBearings
Pre-LoadAdjustment
Removedustcapfromcasterandtightennyloc
nutuntilwashersareat.Backoff1/4ofaturn
toproperlysetthepre-loadonthebearings.If
disassembled,makesurethespringdiscwashersare
reinstalledasshowninFigure36andFigure37.
Figure36
RearCaster
1.Springdiscwashers
Figure37
FrontCaster
HopperDoorAdjustment
DoorClosing:
46

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
