Operation
DisengagingthePTO
1.Setthethrottletothe“MIDWAY”position.
2.PushPTOleverdowntothe“STOP”position
stoppingthePTOandblower.
StoppingtheEngine
1.Bringtheunittoafullstop.
2.DisengagethePTO.
3.Movespeedcontrollevertotheneutralposition.
4.Engagetheparkingbrake.
5.Placethethrottlemidwaybetweenthe“SLOW”
and“FAST”positions.
6.Allowtheenginetorunforaminimumof15
seconds,thenturntheignitionswitchtothe
“OFF”positiontostoptheengine.
7.Removethekeytopreventchildrenorother
unauthorizedpersonsfromstartingengine.
DrivingtheMachine
CAUTION
Machinecanspinveryrapidlybypositioningone
levertoomuchaheadoftheother.Operatormay
losecontrolofthemachine,whichmaycause
damagetothemachineorinjury.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemakingsharp
turns.
Important:Tobeginmovement(forwardor
backward)theoperatormustbeintheseat,the
brakelevermustbedisengaged(pusheddown)
beforethespeedcontrollevercanbemoved
forwardortheenginewillstop.
DrivingForward
1.Starttheengine.
2.Releasetheparkingbrake.
3.Tomoveforwardinastraightlinemovethespeed
controlleverforward.
Toturnleftorright,pulloneofthesteeringlevers
backtowardneutralinthedirectiondesired.
Themachinewillmovefasterthefartherthe
speedcontrolleverismovedawayfromneutral.
4.Tostop,pullthespeedcontrolleverbacktothe
neutralposition.
DrivinginReverse
1.Tomoverearwardinastraightlineapplyingequal
pressurepullbothsteeringleversrearward.
Toturnleftorright,releasepressureonthe
steeringlevertowardthedirectiondesired.
2.Tostop,releasethesteeringleverstotheneutral
position.
AdjustingtheCuttingHeight
Thecuttingheightofthemowerdeckisadjusted
from1to4inches(2.5cmto10.2cm)in1/4inch
(.63cm)increments.
1.Stopthemachineandmovethespeedcontrol
leverstotheneutralposition.
2.DisengagethePTO.
3.Engagetheparkbrake.
4.Stoptheengine,removethekeyandwaitforall
movingpartstostop.
5.Movecotterpinsonfourdecksupportpinsto
properholeforheightofcutdesired.
RaisingtheMowerDeckintoService
Position
1.Stopengine,waitforallmovingpartstostopand
removekey.Engageparkingbrake.
WARNING
Incorrectlyraisingorloweringamowerdeck
canbedangerous.Adroppedmowerdeck
canresultinaseriousinjuryorproperty
damage.
•Alwaysraiseandlowerdeckonat,dry
ground,freeofanyobstructions.
•Firmlygraspthedecklifthandleand
lowerinaslowcontrolledmanner.
•Alwaysmakesurethedeckissecurely
latchedinthe“up”or“down”position.
2.Releasethedecklockingpinsoneachside
(Figure7).
23

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
