Operation
Figure7
1.Decklifthandle
2.Rotatethedecklockingpintowardtherearandpull
outwardtounlock.
3.Pushthedecklockingpininandrotatetowardthefront
tolock.
3.Usingdecklifthandle,liftdeckupandlatchin
“up”position(latchislocatedatfrontcenterof
seat)(seeFigure8).
Figure8
1.Securethedeckin
theraisedpositionby
securingthedecklatch
ontothehook.
2.Hook
WARNING
Operatingthemowerdeckintheraisedservice
positioncanbedangerous.EngagingthePTO
withadeckintheraisedpositioncanresultina
seriousinjuryorpropertydamage.
Alwayslowerandlockmowerdeckinthe
operationpositionbeforeengagingthePTO.
LoweringtheMowerDecktothe
OperatingPosition
1.Whilermlyholdingontodecklifthandle,
unhookdecklatchfromtractorsectionandslowly
lowerdecktoground(seeFigure8).
2.Pushdecklockingpinsinwardandrotateforward
tosecurelylockdeckinloweredposition(see
Figure7).
WARNING
Operatingmowerwithoutlockingpinssecurely
latchedcanresultinthemowerdeckfolding
upunexpectedly.Themowerdeckfoldingup
unexpectedlycancauseseriousinjury.
Alwaysoperatemowerwithlockingpinssecurely
latched.
AdjustingFillReductionSystem
(FRS)Bafes
TheNavigator’sexclusiveFillReductionSystemhas
beendesignedtoallowyoutoreducetheamountof
clippingscollectedbyvaryingdegrees.
Advantagesincludelessfrequentemptyingofthe
hopperandreturnofnutrientstothesoil.
PossibleCongurations:
1.Bafesopen,standardblades–Maximum
collection
2.Bafesclosed,standardblades–Partialmulching
3.Bafesclosed,mulchblades–Intermediate
mulching
4.Mulchpluginstalled,mulchblades–Complete
mulching(requiresmulchkit)
ToadjusttheFRSbafes:
1.Stopengine,waitforallmovingpartstostopand
removekey.Engageparkingbrake.
24

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
