Operation
2.Removehairpinsandclevispinsfrombothsides
ofthePTOguard(seeFigure9).Foldguard
forward.
Figure9
3.LoosennylocnutsontherearstudsoftheFRS
bafes.
Figure10
1.PTOguardremovedfor
clarity
2.Loosennylocnuts
4.RaisedeckasstatedinRaisingtheMowerDeck
totheServicePositionsection.
5.Removeboltandwasheratthefrontofeach
oftheFRSbafes.Rotatebafesintodesired
positionandreinstallboltandwasher.
Figure11
1.Bafesshowninclosedposition
2.Bafesshowninopenposition
3.Bolt
4.Washer
5.Bafes
6.LowerdeckperLoweringtheMowerDeckto
theOperatingPositionsection.
7.SnugnylocnutsontherearstudsoftheFRS
bafes.Thesenutsmaybeleftslightlylooseif
frequentbafeadjustmentisanticipated.
8.ReinstallPTOguardusingclevispinsandhair
pinsremovedinstep2.
25

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
