Exmark NAVIGATOR User Manual

Operation
RemovingtheDeck
WARNING
OperatingaNavigatortractorwithoutan
approvedExmarkfrontmountattachment
increasesthepossibilityofoperatorentanglement
indrivewheelsorforwardtipover.Entanglement
ortip-overcouldcauseseriousinjuryordeath.
WhenoperatingaNavigatortractorwithout
anapprovedExmarkfrontmountattachment,
observethefollowing:
•Keepfeetandclothingawayfromtires.
•Limitoperationtominimumrequiredto
installadifferentfrontmountattachment.
•Minimizespeedanduseextremecaution.
•Onlyoperateonaatlevelsurface.
•DoNotoperateupordownatrailerramp.
•Avoidsuddenaccelerationordeceleration.
Important:DoNottransportNavigatortractor
withoutanapprovedExmarkfrontmount
attachment.
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Raisemowerdeckupandlatchwithdecklocking
pinsperRaisingtheMowerDecktothe
ServicePositionsectioninOperation.
3.Removehairpinsandwashersatthetopofthe
deckliftassistspringoneachsideoftheunit(see
Figure12).
Figure12
1.Springanchorpinunderconsole
2.Securespringswithawasherandhairpin
3.Slidespringontospringanchorpin
4.Removethespringfromthespringanchor.
Repeatforothersideofunit.
5.Un-latchdeckfromraisedpositionandslowly
lowerdecktogroundperLoweringtheMower
DecktotheOperationPositionsectionin
Operation.
Note:Deckwillbecomeheavieroncespringsare
removedfromtheanchors.Lowerdeckcarefully.
6.Removelynchpinsatfrontofpusharmsonboth
sidesoftheunit(seeFigure13).
26
