Exmark NAVIGATOR User Manual

Operation
Figure13
1.Slidethepusharmintothedeckpusharmtube
2.Securethepushpinarmwithlynchpin
7.Removehairpinandclevisfrombothsidesofthe
PTOguard(seeFigure14).
Figure14
1.SecurePTOguardwithclevispinandhairpin
8.Raiseseatanddisconnectdriveshaftusingquick
coupleratjackshaft(seeFigure15).
Figure15
1.Jackshaft2.Driveshaft
9.Pullmowerdeckforwardtoremovefromunit.
InstallingtheDeck
Important:DoNottransportNavigatortractor
withoutanapprovedExmarkfrontmount
attachment.
1.Stopengine,waitforallmovingpartstostopand
removekey.Engageparkingbrake.
2.RollthemowerdeckuptotheNavigatortractor
withthedischargetubedown,makingsurethe
deckspringsarelocatedabovethedrivewheel
andbelowtheconsoleoneachside.
3.Raiseseatandinstalldriveshaftontojackshaft
(seeFigure15)
4.Aligndeckpusharmtubestotractorpusharms
andpushdeckrearward.Securepusharmswith
lynchpinsonleftandrightsidesoftheunit(see
Figure13).
5.AlignupperportionofthePTOrubberguardto
thetabsonthefrontoftheconsoleandsecure
withaclevispinandhairpinoneachside(see
Figure14).
6.Releasethedecklockingpinsoneachside,raise
mowerdecktotheservicepositionandsecure
decklatchontohook.SeeRaisingtheDeckto
theServicePositionsectioninOperation.
27

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
