ProductOverview
BoltLocation
Torque
EngineMountingBolts
30-35ft-lb(41-47N-m)
WheelLugNuts
85-105ft-lb(115-142
N-m)
WheelHubNuts115-135ft-lb
(156-183N-m)
WheelMotorMounting
Bolts
30-35ft-lb(41-47N-m)
ProductOverview
g260634
Figure3
1.Heightofcutpins3.Controls
2.Parkbrakelever4.Motioncontrols
13
