Exmark STARIS E Series - Safety Interlock System Testing; Engine Starting Circuit Verification

Maintenance
CheckSafetyInterlockSystem
Important:Itisessentialthatoperatorsafetymechanismsbeconnectedandinproperoperating
conditionpriortouse.
Note:Ifmachinedoesnotpassanyofthesetests,DoNotoperate.ContactanAuthorizedServiceDealer.
ChecktheNormalEngineStartingChart
ServiceInterval:Beforeeachuseordaily
Note:Itisnotnecessaryfortheoperatortobeontheplatformtostarttheengine.
System
PTO(Blades)
MotionControlLeversOutcome
Disengaged
Bothleversout(neutral)
Startershouldcrank
Upposition,butblades
disengaged*
Bothleversout(neutral)
Startershouldcrank
StateofSystem
*Note:ThestarterwillcrankwiththePTOswitchinthe“ON”(pulledup)position;however,thesystemwill
disengagethePTOandaresetPTOerrorwilloccur.EngagingthePTOwillrequiretheoperatortoresetthe
PTOswitchbyturningit“OFF”(pusheddown)andthenturningit“ON”.
CheckEngineStartingCircuitChart
Note:IntheCheckEngineStartingCircuitChart,thestateofsystemitemthatisboldisbeingchecked
ineachscenario.
System
PTO(Blades)
MotionControlLeversOutcome
Disengaged
BothleversnotinneutralStartermustnotcrank
EngagedBothleversinneutralStartermustnotcrank
StateofSystem
