FOX3 T 201 Transmitter • SIS Configuration and Control 21
X1&
= Verbose mode 0 = Clear/none (default for Ethernet)
1 = Verbose mode (default for RS-232)
2 = Tagged response for queries
3 = Verbose mode and tagged responses for queries
X1*
= Active fiber link 1 = SFP A 2 = SFP B
X1(
= Input HDCP Authorization 0 = HDCP authorized off 1 = HDCP authorized on (default)
X2)
= Resolution and refresh rate nnnnHorizontalxnnnnVertical@xxHz (example: 3840x2160@59.9Hz)
(0000x0000@000Hz = no input detected)
X2!
= Detected audio input format 0 = Not detected 1 = Digital 2 = Analog
X2@
= Detected Video input color 0 = Not detected 1 = YUV 2 = RGB
space format
X2#
= Detected pixel clock 4‑digit response with 0 padding (example: 297 = 0297MHZ)
(0000 = No pixel clock detected)
X2*
= Fiber link detection 0 = Not Detected 2 = Detected
X2(
= Fiber optic mode SM or MM
X3)
= Enable or Diable 0 = Disabled 2 = Enabled
X3!
= Timeout The number of seconds before timeout on IP connections
(min=1, max=65000, with each number equivalent to 10 seconds
[default=30=300 seconds])
X3@
= Force 4K60 compressed mode 0 = Disable (default; after a reset, setting defaults back to 0)
1 = Force 4K60 on 1 fiber
X3#
= View audio output 1 = Digital 2 = Analog
X3$
= Enable Telnet port 23 0 = Off (default) 23 = Telnet port 23 enabled
X3%
= Port number Response is 5 digits with leading zeros, for example 00000 or 00023
