FOX3 T 201 Transmitter • Introduction 1
Introduction
WARNING: The FOX3T201 output continuous invisible light (Class 1 rated),
which may be harmful to the eyes; use with caution.
AVERTISSEMENT : Le FOX3T201 émet une lumière invisible en continu (conforme à
la classe1) qui peut être dangereux pour les yeux, à utiliser avec précaution.
• Do not look into the rear panel fiber optic cable connectors or into the fiber optic
cables themselves.
• Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau
arrière ou dans les câbles fibre optique eux-mêmes.
• Plug the attached dust cap into the optical transceiver when the fiber optic cable is
unplugged.
• Branchez la protection contre la poussière dans l’ensemble émetteur/récepteur
lorsque le câble fibre optique est débranché.
About this Guide
This guide contains information about the Extron FOX3T201 fiber optic transmitter.
Product Description
The FOX3T201 transmitter is a ultra-high performance fiber optic extender for long haul
transmission of the following over two fiber optic cables (see figure1 on page2):
• Uncompressed or visually lossless HDCP-compliant 4096x2160 or 3840x2160 (UHD)
@60Hz video HDMI video
• 2-CH LPCM audio
• RS-232 and IR control signals
The transmitter extends HDMI signals up to:
• 20 km (12.4 miles) for the singlemode cables
• 500 m (1640 feet) with 50 µm OM4 4700 MHz bandwidth laser optimized multimode
cables
(see Fiber Cable Transmission Modes on page2).
The transmitter converts the HDMI video, the selected audio, and the RS-232 serial
communication into two proprietary data streams and outputs them as optical signals via
fiber optic small form factor pluggable (SFP) modules on two LC connector to a compatible
Extron FOX3 fiber optic receiver.
The transmitter has many controls, including audio adjustments, that are available under
Remote RS-232 and USB port Simple Set Instruction (SIS) control and PCS.
NOTE: The FOX3 products are not compatible with legacy FOX, FOXBOX, FOX II,
PowerCage 401 FOX, or PowerCage 1600 FOX products.
