IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 47
X5(
= HDCP mode 0 = follow the input (default)
1 = always encrypt HDMI outputs
2 = follow the input with continuous DVI trials
3 = always encrypt the HDMI outputs with
continuous DVI trials
X6)
= EDID emulation or output
rate
0 = automatic (matches the current output
resolution; default for EDID emulation only)
1 = output A (available for EDID export only)
2 = output B (available for EDID export only)
3 = custom EDID or output rate 1
4 = custom EDID or output rate 2
5 = custom EDID or output rate 3
6 = custom EDID/output rate 4
7 = custom EDID/output rate 5
8 = custom EDID/output rate 6
9 = output C (available for EDID export only;
IN1608 Series)
201 = custom EDID/output rate 7
202 = custom EDID/output rate 8
SIS Variables for EDID Resolution and Refresh Rate Combinations (where X6) = 10-92)
Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz 75 Hz
640x480
10 11 12
800x600
13 14 15
852x480
16 17 18
1024x768
19 20 21
1024x852
22 23 24
1024x1024
25 26 27
1280x768
28 29 30
1280x800
31 32 33
1280x1024
34 35 36
1360x765
37 38 39
1360x768
40 41 42
1365x768
43 44 45
1366x768
46 47 48
1365x1024
49 50 51
1440x900
52 53 54
1400x1050
55 56
1600x900
57 58
1680x1050
59 60
1600x1200
61 62
1920x1200
63 64
480p
65 66
576p
67
720p
68 69 70 71 72 73*
1080i
74 75 76
1080p
77 78 79 80 81 82 83 84
2048x1080 (2K)
85 86 87 88 89 90 91 92
* = Default output resolution
