IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 46
X4^
= Volume group number
1 = program volume
3 = mic volume
8 = variable volume
X4&
= Group volume level -1000 to 0, where -1000 = -100 dB or
0% volume and 0 = 0 dB or 100% volume
X4*
= Mute group number 2 = program mute
4 = mic mute
7 = output mute
X4(
= Bass and treble group
number
5 = bass control
6 = treble control
X5)
= Bass and treble level -240 to +120, where -240 = -24 dB and
+120 = 12 dB
X5!
= Increment value dB value multiplied by ten, in 0.1 dB increments,
to raise or lower a group fader (for example,
100 = 10 dB)
X5@
= Password Up to 12 digits and alphanumeric characters for
user or admin passwords.
NOTE: / \ | * and space are invalid characters.
X5#
= Verbose mode 0 = clear or none (default for Telnet connections)
1 = verbose mode (default for RS-232)
2 = tagged responses for queries
3 = verbose mode and tagged for queries
X5$
= Auto switch mode 0 = disable (default)
1 = prioritizes the highest numbered active input
2 = prioritizes the lowest numbered active input
X5%
= Video mute on all outputs
0 = all outputs are unmuted
1 = at least one output is muted
2 = at least one output is muted and sync is
disabled
X5^
= Volume knob group number 1 = program volume (default)
3 = mic volume
8 = output volume
X5&
= Gain or mute control 40100 = mic 1 (mix volume only)
40000 = mic 1 (mute only)
40101 = mic 2 (mix volume only)
40001 = mic 2 (mute only)
60000 = output 1
60002 = output 2
60004 = variable output L
60005 = variable output R
60006 = digital output L
60007 = digital output R
60008 = amplified output L (stereo models) or
amplified output (mono models)
60009 = amplified output R (stereo models)
X5*
= Gain or trim level -1000 to 0 = dB value multiplied by ten, in 0.1
dB increments, (for example, -100 = -10 dB)
0 = default
