IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 59
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Overscan mode (applies only to SMPTE input resolutions)
Set value
EX#*X2% OSCN} OscnX#*X2%] Set the overscan value to X2%.
View status
EX#OSCN} X2%]
View the overscan setting.
HDCP notification (displayed on non-HDCP displays with HDCP input selected)
Enable notification
EN1HDCP} HdcpN1]
Display a green screen.
Disable notification
EN0HDCP} HdcpN0]
Mute output to black.
Query notification
ENHDCP} X(]
View the HDCP notification setting.
HDCP status
Query input
EIX!HDCP} X3)]
HdcpIX!*X3)]
View the HDCP status on input X!
(inputs 3+ only).
Verbose modes 2 and 3
Query output
EOX@HDCP} X3)]
HdcpOX@*X3)]
View the HDCP status on output X@.
Verbose modes 2 and 3
HDCP authorized setting (valid for HDMI inputs only, to allow or block HDCP input signals)
Enable HDCP
authorization
EEX!*1HDCP} HdcpEX!*1]
Enable HDCP authorization
(inputs 3+ only).
Disable HDCP
authorization
EEX!*0HDCP} HdcpEX!*0]
Disable HDCP authorization
(inputs 3+ only).
Query HDCP
authorization status
EEX!HDCP} X3(]
View HDCP authorization setting
(inputs 3+ only).
NOTES:
X! = Input selection
1-6 (IN1606) or 1-8 (IN1608 Series)
X@ = Output selection
1 = HDMI A (top)
2 = HDMI B (bottom)
3 = Out C
X# = Input video format
1 = RGB
2 = YUV
3 = RGBcvS
4 = S-video
5 = Composite
6 = HDMI
X( = Enable or disable
0 = off or disabled
1 = on or enabled
X2% = Overscan
0 = 0.0% (default for RGB and HDMI)
1 = 2.5% (default for YUV, RGBcvS, S-Video, and CV)
2 = 5.0%
X3) = HDCP status
0 = no sink or source device detected
1 = sink or source detected with HDCP
2 = sink or source detected but no HDCP is present
X3( = HDMI input HDCP authorization status
0 = block HDCP encryption
1 = allow HDCP encryption (default)
