IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 60
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
HDCP mode (valid for HDMI outputs only)
Set HDCP mode
ESX5(HDCP} HdcpSX5(] Set the HDCP mode to X5(.
View HDCP mode
setting
ESHDCP} X5(]
HdcpSX5(]
View the HDCP mode.
Verbose modes 2 and 3
Video signal presence
View video signal
presence status
E0LS} X3^*X3^*...X3^*X3^]
View video signal presence for all
inputs.
In00
•
X3^
*X3^*X3^*X3^*X3^]
Verbose modes 2 and 3
NOTES:
X3^ = Video signal status
0 = video/HDMI signal not detected
1 = video/HDMI signal detected
X5( = HDCP mode
0 = follow the input (default)
1 = always encrypt HDMI outputs
2 = follow the input with continuous DVI trials
3 = always encrypt the HDMI outputs with
continuous DVI trials
