IPCP Pro Series • Hardware Features and Installation 17
Figure 13 shows how the IPCPPro looks after it is mounted, before cables are connected.
GTx Rx GTx Rx
COM 2 COM 3
RELAYS
21 43 CC
COM 1
GTx Rx
RTS CTS
LAN
IR/SERIAL
1
S
G
2
S G
1 2 3 4 G
DIGITAL I/O
IR
R
eBUS
+V +S
-S
G
PWR OUT = 6
W
IPCP PRO 355DR
12V
1A MAX
POWER
AV LAN
Figure 13. The IPCPPro Mounted on a DIN Rail, Before Cabling
