Extron electronics IPCP Pro Series User Manual

IPCP Pro Series • Hardware Features and Installation 27
1000
LINK
ACT
AV LAN
12
3
L
A
N
1
L
AV LAN PortLAN Port
LA
AN
AV
LAN
M
A
C
:
00
-
0
05
-A
6-
XX-XX-X
X
X-
X
X
X
S/
N: ###
#
#
###
E###
E
##
#
##
#
MAC: 00-05-A6-YY-YY-YY
S/N: ####### E######
LAN
21
PWR PWR
3
PoE+ OUT PoE+ OUT
AV LAN
MA
C
:
00
-
05
-A
6-
YY
-
YY
-
YY
S/
N: ##
#
#
#### E#####
#
00-
0
0
5-A6-XX-X
X
X
-XX
I
P
C
P LAN
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
00-05-A6-XX-XX-XX
IPCP AV LAN
RJ-45
Connector
Insert Twisted
Pair Wires
Pins:
12345678
Rear Panels,
Rack Mount Models
Front Panels,
Rack Mount
Models
Bottom Panel
IPCP Pro 355DR
NOTE: IPCPs with more than one LAN or
AV LAN port function as multiport,
unmanaged network switches so you
can connect additional devices to the
same network.
Ethernet
or
Ethernet
1000 Mbps
Connection
Network is
active.
Data is being
sent/received.
AV LAN (Ethernet)
Default protocol, AV LAN:
• IP address:
192.168.254.250
• Subnet mask:
255.255.255.0
• DNS address: 127.0.0.1
• DHCP server off (disabled)
• Link speed and duplex
level: autodetected
• Data rates:
10/100/1000Base-T
Default login credentials:
• Username: admin
• Password: extron
PC
AV LAN DHCP Server
The AV LAN DHCP Server is disabled by default. It can be enabled to dynamically assign
IP addresses to DHCP clients on the AV LAN.
AV
Network
PC
AV
Network
Default protocol, AV LAN when
DHCP server is enabled:
• DHCP server IP address: 192.168.254.1
• Subnet mask: 255.255.255.0
• DNS address: 192.168.254.1
• DHCP dynamic address range for client
devices: 192.168.254.100 -
192.168.254.149
• Maximum served addresses when
DHCP server is enabled: 50
• DHCP client address lease time: 24 hours.
To use DHCP in the AV LAN:
1. Using Toolbelt, enable the DHCP server
for the AV LAN within the control
processor (see the software or
programming help le for details).
2. Enable DHCP on each client AV device
(see the user guide for each product).
3. Connect client AV devices to the AV LAN.
Link
LED
Activity
LED
Figure 23. Models with AV LAN:
AVLAN Connector, LEDs, and Default Protocol
M
MAC address (see figure 14, figure 15, and figure 16
on page18 through page20) — Each network
interface of the control processor is assigned a unique user
hardware ID number (Media Access Control [MAC]
address) (for example, 00-05-A6-05-1C-A0). You may
need this address during control processor configuration. A
label that indicates the MAC address is located on the rear or side panel of each rack-
mounted model and on the side or bottom panel of each DIN rail model.
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
00-05-A6-XX-XX-XX
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
MAC
Address
