EXXFIRE 750CNF - Page 34

version 4.7.2 – July 10th, 2022 Firmware version V2.1.7 and higher
EXXFIRE Installation and Service Manual 34
#
Part
Inside
mounting
Outside
mounting
Article number
MOUNTINGKIT2
MOUNTINGKIT3
1
28 mm gas deployment pipe (length: 495
mm)
2
2
2
Silencer with push-fit fitting
1
1
3
Pipe grommet
1
4
Pipe fitting disconnecting tool, see
Chapter 12
1
1
5
Left 19” mounting bracket
1
6
Right 19” mounting bracket
1
7
M6 bracket bolt and cage nut
6
8
Power cord (EUR)
1
1
9
Cable grommet
4
10
M6 mounting plate bolt and nut
6
11
Mounting plate
1
12
Mounting plate screw
2
13
Air-sampling nozzle with air tube, 1,5 mtr
1
1
14
90° angle 28mm pipe fitting (push-fit)
1
1
15
Straight 28 mm pipe fitting (push-fit)
1
1
16
Front mounting bracket
2
17
Drilling template (not in figure)
1
18
Door Warning Sticker (not in figure)
1
1
Table 7 Mounting kit contents
