version 4.7.2 – July 10th, 2022 Firmware version V2.1.7 and higher

EXXFIRE Installation and Service Manual 37

Mounting

The EXXFIRE® 750CNF/1500CNF/2250CNF is suited for:

• Outside the protected enclosure mounting - On top of the protected space, e.g. a cabinet, see

Section 4.4.1.

• Inside the protected enclosure mounting - Within the mounting rails of a 19” rack, see Section

4.4.2

4.4.1 Outside the protected enclosure mounting

1. Take out the boxed EXXFIRE® 750CNF/1500CNF/2250CNF and the mounting kit from the box.

2. Collect the necessary parts from the mounting kit, see Section 4.2

3. Unpack the needed Cool Gas Generator(s)

4. Collect the necessary tools, see Section 4.3.

5. Define the best entrance for the gas pipe and aspiration tube.

6. Define the mounting position for the EXXFIRE® 750CNF/1500CNF/2250CNF on top of the

protected space and place the drilling template.

Make sure that the air sampling input and gas output and the to-be-installed piping or tubing are

not obstructed.
