EXXFIRE 750CNF - Page 52

version 4.7.2 – July 10th, 2022 Firmware version V2.1.7 and higher
EXXFIRE Installation and Service Manual 52
22. Fasten the system with the 4x provided screws to secure the system at the front side of the rack
Figure 40 Mounting screws
23. Install piping.
Firmly push the angle connector onto the outlet pipe of the unit.
Figure 41 Installing piping
