Rotary control and push button = dual function
Momentarily pushing the F/CH knob
while in the USE/STBY or DIRECT TUNE mode changes the access
from kHz to MHz or vice versa from MHz to kHz.
If there is no activity for 30 seconds the F/CH knob will return to the kHz
access.
While in the CHANNEL mode pushing the F/CH knob is without
function.
Rotating the F/CH knob
while in the USE/STBY mode will increment or decrement the MHz or
kHz portion of the STBY frequency with rollover at each band edge,
while in the CHANNEL mode changes the channel memory number
and corresponding frequency. Only channel numbers which were
programmed before will appear,
while in the DIRECT TUNE mode will increment or decrement the MHz
or kHz portion of the USE frequency with rollover at each band edge.
Push button
Up to 99 frequencies/channel names in each Operating mode (combined
8.33/25 kHz mode and '25 kHz only' mode) may be stored in a non-
volatile memory. The channel memory numbers (1 99) are user
programmable.
Programming a frequency:
1. Set the frequency or channel name to be stored in the upper line at
the display!
2. Initialize storing by pushing the STO button.
3. The last used channel memory number is displayed in the lower line.
4. A flashing "CH" shows "ready to store".
5. Select appropriate (new) channel memory number (1 to 99) by
rotating the F/CH knob.
6. On a free channel memory an additional "F" (free) is displayed (CH 5
to 99).
7. To enter the new frequency/channel name push the STO-button. The
frequency/channel name will be stored under the adjusted channel
memory number.
8. A previously stored frequency/channel name will be overwritten.
9. The last used Operating mode is displayed.
Programming in the SET-UP mode:
In the SET-UP mode all settings must individually be confirmed by
pushing the STO button. Otherwise the settings are not permanently
stored.
