FSG 90 System
Appendix A
December 2014 FAV_D10024 59
A.2 Dimensions, Weight, Fuses
Front Panel
57 mm dia / 2¼ in. dia, fits a standard panel opening
Depth behind panel
200 mm / 7.85 in. (allow 30 mm/1.2 in. for plugs and
harness)
Overall Dimensions
Width = 63 mm/2.5 in., Height = 58 mm/2.28 in., Depth =
223 mm/8.78 in.
Weight FSG 90
0.80 kg/1.77 lb. without harness and mating connectors
Weight FSG 90-H1
0.82 kg/1.81 lb. without harness and mating connectors
External Fuse
6 W model: Cartridge fuse 3.15 Amp, quick acting, or
automatic circuit breaker, 3 Amp
10 W model: Cartridge fuse 5 Amp, quick acting, or
automatic circuit breaker, 5 Amp
Inline Fuse, switched/regulated DC Output
315 mAmp, medium time lag
A.3 Approvals
Airborne Radio (Regulatory Authority For
Telecommunications and Posts)
“EC Type-Examination Certificate” no. B132705J, and
”TYPE-EXAMINATION CERTIFICATE” no. A132937J
Airborne Radio (Regulatory Authority For
Telecommunications and Posts, and LBA)
Reg TP 321 ZV 034
EUROCAE ED-23B:
Receiver Class C 25 kHz spacing CLIMAX operation,
and
Receiver Class E 8.33 kHz spacing
Transmitter Class 4 100 NM with 25 kHz spacing, and
Transmitter Class 6 100 NM with 8.33 kHz spacing
Environmental Requirements EUROCAE ED-14C / RTCA
DO-160C:
Categories D1-AA(BMN)XXXXXXZBBBATZ(A3C2X)XXX
ETSO-Authorization (LBA, airborne)
ETSO-2C37e and ETSO-2C38e
No. LBA.O.10.911/98 JTSO
replaced by EASA.21O.1305
Software
EUROCAE ED-12B / RTCA DO-178B, Level D
Ground Operation (BAF)
D-0036/2014 (FSG90)
D-0037/2014 (FSG90-H1)
