F.u.n.k.e. FSG 90 - Transmitter Blocking Configuration

FSG 90 System
5 SET-UP Procedure
46 FAV_D10024 December 2014
5.4.10 Selecting 'TRANSMITTER BLOCKING' during receive (ON/OFF)
IMPORTANT!
 Whenever 'Transmitter Blocking' is ON and squelch is ON, transmitting is
disabled as long as the frequency/channel name is busy (communication
audible).During that, no Sidetone is audible, even if PTT is pressed and
one is talking into the microphone.
 Whenever the squelch is OFF 'Transmitter Blocking' is OFF and
transmitting is possible even on a busy channel.
The display shows in the upper line alternately »SET« and »BLOC«,
in the lower line »0« or »1«.
Adjust by rotating the F/CH knob the lower line to »0« or »1«.
0 = 'Transmitter Blocking' is OFF. Transmitting is always
possible, even on a busy channel.
1 = 'Transmitter Blocking' is ON. With squelch ON transmitting is
only possible on a free channel.
 Confirm your adjustment by pushing the STO button!
 Carry on with the SET-UP procedure by pushing once or
repeatedly the MD button till the desired menu appears.
5.4.11 Service (ON/OFF)
IMPORTANT!
 For approved Avionics Shops only!
The display shows in the upper line alternately »SET« and »SERV«,
in the lower line »0«.
0 = STANDARD MODE, Service OFF.
 If required, confirm adjustment by pushing the STO button!
 Carry on with the SET-UP procedure by pushing the MD button.
5.4.12 Optional module (ON/OFF)
IMPORTANT!
 Not applicable with this radio.
The display shows in the upper line alternately »SET« and »OPTI«,
in the lower line »0«.
0 = STANDARD MODE, Optional module OFF.
 Carry on with the SET-UP procedure by pushing the MD button.
