FSG 90 System
5 SET-UP Procedure
December 2014 FAV_D10024 45
If further memory channels should be deleted adjust with the F/CH
knob the channel memory number concerned and delete each by
pushing the STO button.
If you want to carry on with the SET-UP procedure push once or
repeatedly the MD button till the desired menu appears.
5.4.8 Selecting AF EXTERNAL via A/C speaker (ON/OFF)
IMPORTANT!
Always switch OFF AF EXTERNAL ("0") when the radio FSG 90(X) is
battery powered. It saves approximately 30 mAmps.
The display shows in the upper line alternately »SET« and
»AF - E«, in the lower line »0« or »1«.
Adjust by rotating the F/CH knob the lower line to "0".
0 = AF EXTERNAL OFF, AF external only audible via headphones
1 = AF EXTERNAL audible via aircraft speaker
Confirm the adjustment by pushing the STO button, if required!
Carry on with the SET-UP procedure by pushing once or
repeatedly the MD button till the desires menu appears.
5.4.9 Selecting 'CHANNEL MODE ONLY' or 'NO RESTRICTION'
IMPORTANT!
For certain applications (usually ground operation only) free selection of
all frequencies by the operator may be restricted. Then transmitting and
receiving is only possible in the CHANNEL MODE, pre-programmed
before by authorized personnel.
The display shows in the upper line alternately »SET« and »FREQ«,
in the lower line »0« or »1«.
Adjust by rotating the F/CH knob lower line to "0" or "1".
0 = Standard operation, free frequency selection, no restriction.
1 = CHANNEL MODE only, no other frequencies/channel
names adjustable by operator.
Confirm your adjustment by pushing the STO button!
Carry on with the SET-UP procedure by pushing once or
repeatedly the MD button until the desired menu appears.
