FSG 90 System
Appendix C
66 FAV_D10024 December 2014
Appendix C, ICAO Frequency-Channel Pairing
The table below shows TX and RX frequency, respective channel spacing and the
corresponding channel name or frequency, which is shown at the display of the FSG 90
in the range from 118.000 MHz to 118.1000 MHz.
In combined 8.33 kHz / 25 kHz channel spacing mode, the active Channel Name is
displayed with 6 digits.
In "25 kHz only" channel spacing mode, frequencies are displayed with 5 digits.
This allows unique identification of the mode used.
Of course this frequency-channel pairing plan also applies to all other frequencies
between 118.1000 MHz and 136.9750 MHz.
Operating frequency
(MHz)
Channel Spacing
(kHz)
8.33/25 kHz Mode
Channel Name =
Display at FSG 90
25 kHz Mode
Frequency =
Display at FSG 90
118.0000
25
118.000
118.00
118.0000
8.33
118.005
118.0083
8.33
118.010
118.0166
8.33
118.015
118.0250
25
118.025
118.02
118.0250
8.33
118.030
118.0333
8.33
118.035
118.0416
8.33
118.040
118.0500
25
118.050
118.05
118.0500
8.33
118.055
118.0583
8.33
118.060
118.0666
8.33
118.065
118.0750
25
118.075
118.07
118.0750
8.33
118.080
118.0833
8.33
118.085
118.0916
8.33
118.090
118.1000
25
118.100
118.10
118.1000
8.33
118.105
etc.
etc.
etc.
etc.
