FAAC 400 Series User Manual

400 7 732871 - Rev. D
Translation of the original instructions
ENGLISH
3.6 TECHNICAL CHARACTERISTICS
The 400 is a hydraulic actuator for swing gates. The system consists
of an electric motor that displaces the oil in the hydraulic circuit by
means of a pump and actuates the piston. The piston rod is fixed to
the leaf in order to transmit movement.
The 400 range of actuators includes different models according to:
type of hydraulic lock, stroke of the rod, pump flow rate and type of
oil.
TYPE OF HYDRAULIC LOCK the hydraulic lock makes it impossible to
reverse the movement when the actuator is not in operation and
defines the following models:
- 400 CBAC (with opening and closing lock) The actuator is non-
reversing during both opening and closing. To allow manual
operation, the release manoeuvre must be performed. Electric
locks are not required to maintain the open and closed positions.
- 400 CBC (with closing bock) The actuator is non-reversing during
opening. To allow manual operation during opening, the release
manoeuvre must be performed. The force required to close the
leaf manually, without having released the actuator, depends
on various factors (length of the leaf, by-pass screw adjustment,
installation measurements). It is therefore advisable to carry out
the release manoeuvre. An electric lock is required to maintain
the open position.
- 400 CBA (with opening lock) The actuator is non-reversing during
closing. The release manoeuvre has to be performed in order to
allow manual operation during closing. The force required to open
the leaf manually, without having released the actuator, depends
on various factors (length of the leaf, by-pass screw adjustment,
installation measurements); it is anyway advisable to carry out
the release manoeuvre. An electric lock is required to maintain
the closed position.
- 400 SB (without lock) The actuator is reversible. To allow manual
operation, it is not necessary to perform the release manoeu-
vre. The force required to move the leaf manually, without having
released the actuator, depends on various factors (length of the
leaf, by-pass screw adjustment, installation measurements); it is
anyway advisable to carry out the release manoeuvre. Electric
locks are required to maintain the open and closed positions.
ROD STROKE Long rod actuators (L version) are recommended for
wide pillars.
PUMP FLOW RATE the electric motor and pump assembly determines
the maximum speed of movement of the leaf and the maximum
thrust force. Quick acting actuators are available (version R). The
slow actuators (version S), that deliver a greater force, are suitable
for moving long leaves.
OIL TYPE 400 (FAAC HP OIL), 400 Winter (FAAC HP2 OIL) the Winter versions
are suitable for installation in environments with temperatures as
low as -40°C.
Control system
The 400 must be connected to a FAAC electronic board for controlling
230 V / 115 V motors (depending on the version) for swing gates.
Standard equipment (on all versions)
- Key-protected bypass screws: allow the maximum crushing force
during opening and closing to be regulated.
- Key-protected release device: allows manual operation. When
used with actuators without a lock, it reduces the force required
for manual operation.
1 Technical data
Version 400 CBAC 400 CBC 400 CBA 400 CBAC R 400 CBAC L
Power supply voltage 220
… 240 V~
50/60 Hz
220 … 240 V~
50/60 Hz
220 … 240 V~
50/60 Hz
220 … 240 V~
50/60 Hz
220 … 240 V~
50/60 Hz
Electric motor Asynchronous single phase Asynchronous single phase Asynchronous single phase Asynchronous single phase Asynchronous single phase
Thrust capacitor 8 F 8 F 8 F 8 F 8 F
Thermal protection 120°C 120°C 120°C 120°C 120°C
Max power 220 W 220 W 220 W 220 W 220 W
Max. thrust 6200 N* 6200 N* 6200 N* 4650 N* 4650 N*
Max leaf length 2.2 m 2.2 m 2.2 m 2.2 m 2.2 m
Min leaf length 0.9 m 0.9 m 0.9 m 0.9 m 1.1 m
Rod stroke 270 mm 270 mm 270 mm 270 mm 390 mm
Max. rod speed 10 mm/s** 10 mm/s** 10 mm/s** 15 mm/s** 15 mm/s**
Motor-pump unit flow rate 1 l/min 1 l/min 1 l/min 1.5 l/min 1.5 l/min
Ambient operating temperature
[WINTER version]
-20 °C
… +55 °C
[-40 °C
… +40 °C]
-20 °C
… +55 °C
-
-20 °C … +55 °C
-
-20 °C … +55 °C
-
-20 °C … +55 °C
[-40 °C
… +40 °C]
Type of use Industrial/Commercial Industrial/Commercial Industrial/Commercial Industrial/Commercial Industrial/Commercial
Use frequency 70 cycles/hour 70 cycles/hour 70 cycles/hour 80 cycles/hour 50 cycles/hour
Protection rating IP55 IP55 IP55 IP55 IP55
Oil type
[WINTER version]
FAAC HP OIL
[FAAC HP2 OIL]
FAAC HP OIL
-
FAAC HP OIL
-
FAAC HP OIL
-
FAAC HP OIL
[FAAC HP2 OIL]
Weight 8.9 kg 8.9 kg 8.9 kg 8.9 kg 10.5 kg
* values refer to a 230 V power supply
** values refer to a frequency of 50 Hz
