User’s Manual
V1.1
66
Specifications
VIDEO
Signal Format NTSC or PAL (Auto Detect)
Video Input Composite: 4 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs
Composite: 1 BNC, 1 Vp-p, 75 Ohms
VGA: 1 (Auto Detect)
Video Resolution
Composite: 720x480 (NTSC), 720x576 (PAL)
VGA: 800x600, 1024x768, 1280x1024@60Hz
Playback/Record Speed
(images per second)
120/120ips (NTSC), 100/100ips (PAL) (Full Duplex)
INPUTS/OUTPUTS
Alarm Input 4 TTL, programmable as NC or NO, 4.3V threshold
Alarm Output
1 relay output, terminal blocks, programmable as NC or NO, 2A@125VAC,
1A@30VDC
Alarm Reset Input 1 TTL, terminal block
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Mbps Ethernet (RJ-45)
Audio Input RCA Input: 4 (independent), Line In
Audio Output RCA Output: 1, Line Out
Text Input POS Interface, ATM Interface
CONNECTORS
Video Input Composite: 4 BNC
Video Loop Composite: 4 BNC (Auto Terminating)
Monitor Output
Composite: 1 BNC
VGA: 1 VGA
Audio In 4 RCA connector
Audio Out 1 RCA connector
Alarm Input/Output Terminal blocks
Ethernet Port RJ-45
RS232C Serial Port DB9 (P)
RS485 Serial Port Two-connector terminal block
USB Port 1 (USB 2.0)
IR Port 1 Remote Control
STORAGE
Primary Storage SATA hard disk drive
Secondary Storage USB hard disk drive, CD-RW drive or flash drive
GENERAL
Dimensions (W x H x D) 13.4" x 1.8" x 12.2" (340mm x 46.5mm x 310mm)
Unit Weight 6.6 lbs. (3.0kg)
Shipping Weight 9.9 lbs. (4.5kg)
Shipping Dimensions
(W x H x D)
17.3" x 5.6" x 16.1" (440mm x 143mm x 410mm)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 100–240 V~, 50/60Hz, 0.8–0.4 A
Power Consumption Max. 25W
Approvals FCC, UL*, CE
* CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions. This equipment
is indoor use and all the communication wiring are limited to inside of the building.
Specifications are subject to change without notice.
