Caution
Installation engineers should note that for first
time connection of appliance to
supply, it is essential that
inlet gas supply to fryer is completely purged of air
prior to first lighting attempt. Otherwise, since this is a light pilot first every time
system, it will take a significant number of
tries to light due to the small amount of
air bled from pipe by pilot at each attempt. This should not initially be treated as a
fault.
Please note that several attempts will still be required after air purge for first time
lighting. This is due to the capacity of valve and governor.
2.3 CONNECTION TO AN ELECTRICAL SUPPLY
Ensure flexible cable does not come into contact with any hot parts. The fuse rating should be
13A.
Colour coding of power supply cables is as follows:
Live - Brown, Neutral - Blue, Earth - Green/Yellow
2.4 STARTING UP
G3840/F
If you are in the fat melting cycle and loading solid fat for the first time, always remove basket support
plate as detailed in Section 9. Solid fat
should be in direct contact with fryer pan.
Refer to Section 9.
G3840X/G3840FX
It is recommended that fat is pre-melted before pouring it in to the G3840X/G3840FX for the first time.
G3840/F Fryer Control Panel (See Figure 2)
Figure 2 – G3840 Control panel
1. ON/OFF and Temperature Control Knob
Temperature Selection (140 - 190°C). (Unit is off when control is in position indicated).
2. Fat Melt Position
Feature for slow pulsed heating of solid fats.
3. Power on indicator.
4. Heat Demand Indicator
Illuminates when thermostat demands heat, i.e. oil temperature is more than 5⁰C below
temperature setting. Extinguishes when desired temperature is reached.
