Falcon G3840 - Assembly and Commissioning

9
This appliance is also provided with a terminal for connection of an
external equipotential conductor. This terminal is in effective
electrical contact with all fixed exposed metal parts of the appliance,
and shall allow the connection of a conductor having a normal cross-
sectional area of up to 10mm². It is located on the rear panel and is
identified by the following symbol and must only be used for bonding
purposes.
G3840/G3840X/G3840F/G3840FX
Rated Voltage
Rated Current
230V~
3.55amps
1.6 TOTAL RATED HEAT INPUTS
Appliance
KW
BTU/Hr (gross)
Pilot
G3840 / G3840X / G3840F / G3840FX
Nat (I
2H
)
21.5kW
80,700 btu/h
*0.29kw
*Ignites with main burners
G3840 / G3840X / G3840F / G3840FX
Prop (I
3P
)
22kW
82,600 btu/h
*0.26kw
*Ignites with main burners
1.7 INJECTOR SIZES
Appliance
Main Burners
Pilot
G3840 / G3840X / G3840F / G3840FX
Nat (I
2H
)
2 x Ø2.6mm
Polidoro G31.2
G3840 / G3840X / G3840F / G3840FX
Prop (I
3P
)
2 x Ø1.7mm
Polidoro G25
2.0 ASSEMBLY and COMMISSIONING
The gas supply piping and connection to appliance must be installed in accordance with the local
regulations in conjunction with those listed on the cover of this manual.
2.1 ASSEMBLY
a) Unpack appliance
b) Unpack fryer baskets and accessories.
c) Place basket support grid and basket in pan.
d) Level appliance and fit all service protection kits.
(Anti-tilt kit is supplied).
2.2 CONNECTION TO A GAS SUPPLY
Connect gas supply and test for gas soundness.
Caution
Ensure that pan contains an acceptable level of liquid before igniting burner.
Due to the presence of mains electrics, integral pipe work should be checked for
gas soundness using an appropriate gas leak detector.
