Clearances
The unit requires a clearance of at least 150mm all round between unit and any walls. The unit
must only be installed next to non combustible walls. A minimum vertical clearance of 750mm
should be allowed between top edge of flue outlet and any overlying combustible surface.
Important
If fryer is to be installed with other appliances then the instructions for
every model should be consulted to determine the necessary clearance
to any wall or overlying surface.
Some appliances require greater clearance distances than others. The
largest clearance will therefore determine overall distance for a
complete suite of adjoining appliances.
1.3 VENTILATION
This appliance MUST be installed with sufficient ventilation to prevent the occurrence of
unacceptable concentrations of substances harmful to health in the room in which they are
installed. Installer must consult any additional local / national regulations.
The fresh air requirement for this appliance at a rate of 2M³/hour per kW is 44 M³ is as follows:
COMBUSTION AIR REQUIREMENTS
APPLIANCE
VENTILATION RATE
G3840
44 m
3
/h
G3840X
44 m
3
/h
G3840F
44 m
3
/h
G3840FX
44 m
3
/h
1.4 GAS SUPPLY (All Models)
To be checked at installation, gas conversion or repair.
Note: Governor setting may be checked at burner manifold without the need to remove the right
hand side panel.
To adjust appliance pressure;
The SIT gas valve, situated at rear RH side of unit and accessible by removing RH side, has
an in-built governor.
The supply pressure should be checked at valve inlet test nipple using a manometer.
Burner pressure should be set at test nipple on burner manifold using a manometer.
Checking / Setting values are indicated below (for either natural or propane gas).
This is achieved by removing brass dust screw from valve governor and adjusting governor
accordingly using an approved VDE insulated screwdriver - clockwise rotation increases pressure.
(see illustration) insulated
Warning: To avoid risk of electric shock, all adjustments to the governor
should be made with the appliance switched off and unplugged.
Note: Propane (I
3P
) appliances require governor to be adjusted clockwise to maximum
adjustment.
