Installer settings
28
Analog output 3
Type
Setting if analog output 3 is used:
None
Air inlet combi 10-0V
Air inlet combi 0-10V
Heating 0-10V
Heating 10-0V
Thermal control 0-10V
Thermal control 10-0V
Vortex factor 10-0V
iFan ProFlow 10-0V
A similar setting cannot be made at Type analog output 1, 2 and 3. Air inlet
control, thermal control and Vortex factor can only be assigned to analog
output 1, 2 and 3.
Analog output 3
Correction factor
Setting of the correction factor. If there is a difference between the measured and the
control value (or between the output value and control value, if there is no feedback),
correction will take place. The extent of correction depends on the correction factor
(factor between 0.0 and 1.0). The higher the correction factor, the quicker correction
will take place; with a correction factor of 0.5, the computer will correct half the
difference each control time. With a factor of 1.0, the computer will correct the
difference in a single action.
Analog output 3
Control time(s)
Setting of the control time (seconds). The controller determines if controlling or
adjusting the 0-10V output is necessary at intervals equal to the set control time.
Analog output 3
Correction buffer /
Minimum pos.
Setting of the minimum position (by using heating or thermal) or correction buffer (by
using other control types).
Correction buffer: Each control time the computer registers the difference
between the measured and control value and adds this to any previous
differences. As soon as the total sum exceeds the value of the correction
buffer, the computer will correct the output.
Triac type
Setting the use of triac control:
None
Ventilation
Ventilation DSR
Set to None if iFan ProFlow is used.
Vortex factor
Setting how the vortex damper is coupled to the controllable part of the ventilation.
The computer determines the control value for the vortex damper by multiplying the
controllable part by the factor set here. If this factor is set to 2.0, the vortex damper
will be fully opened when the controllable part is 50%.
Vortex minimum position
Setting of the minimum position of the vortex damper here.
