Fantic XEF 250 - Page 80

4. Maintenance
USE AND MAINTENANCE MANUAL CHAPTER 4
MAINTENANCEXEF 250 - Rev01 / 2020
80
1
2
1
1
3
5
2
4
6
– Install a new gasket “1”;
– Install the clutch crankcase “1” and bolts “2”. Tighten them
following a cross pattern.
Bolt (clutch cover):
10 Nm (1.0 m•kg, 7.2 ft•lb)
– Install the springs and bolts of the clutch and tighten them
following a cross pattern;
Bolt (clutch spring):
10 Nm (1.0 m•kg, 7.2 ft•lb)
