Fanvil i21 - Page 25

25
Password
Configure SIP registration account password
Telephone number
Configure the number registered to the SIP server，
if it is empty，then it is not a registered
Display Name
Configure display names，able to do when calling in
the called party（not name the calling party
）can show this configuration parameter，allow input
English letters
Proxy server address
Configure proxy server IP address（generally，SIP
service provide users the use proxy server and
register the same server configuration to provide
services，thus，the proxy server configuration is
usually is the same as the registered server
configuration,if the service providers give different
registered server from the proxy server IP address
configuration ， need modify their server
configuration）
proxy server port Configure SIP proxy server signaling port
proxy server account Configure proxy server account
proxy server
password
Set the proxy server password
local domain name
Configure the SIP local domain name. If the server
does not require a local domain name to specify the
domain name for a SIP terminal，the local domain
can be configured with the same address or domain
name server.System to simplify the user input，users
can not enter the local domain name，the system will
automatically get registered address fill in the
content of domain realm.
backup proxy server
address
Configure the backup proxy server address，if the
master agent server address is unavailable，phone
will enable backup proxy server address
automatically
backup proxy server
port
Configure the backup proxy server port
Open registration Configure allow/prohibit registration
Codecs
Disable
Codecs/Enable
Codecs
According to the need by navigation on Disable
Codecs/Enable Codecs list add or remove coding，
and can be used by the priority of the up and down
navigation keys to change the coding.
Advance SIP
configuration
Forward Type
Choose call forwarding way. call forwarding（default
it’s close）
 close：close call forwarding function
