Fanvil i21 - Appendix and Management; Technical Specifications and Features

36
5.1.1.Specifications:
Protocol
SIP 2.0(RFC-3261)
Chipset
Broadcom 1190
Key
Key Material
Stainless Steel
Direct-button
1
Digital Keyboard
Support(i21T only)
Voice
Microphone
1
Amplifier
1.5W/8Ω
Speaker
1.5W/8Ω
Voice Control
Adjustable
FDSP
Support(AEC)
Voice Flow
Protocol
RTP
CODEC
G.711, G.729
PORT
Power Supply
12V+-15%/1A DC or PoE
PoE
PoE 802.3af (Class 0 - 12.95W)
48V/380mA
LAN
10/100BASE-TX s Auto-MDIX,
RJ-45（Keep press key in 7 seconds
to play IP）
Recommended Cable
HSYV or better
Passive Switch
Always on and Always close highest
at 30V/1A AC/DC
Active Switched Output
12V/500mA DC
RS232
Support
RFID/IC Card
Reader(Optional)
EM-4100 (125Khz)
Optional
HID Card(125kHz,
26bit)
Not support
M1 Card（13.56MHz） Not support
Structure
Shell Material Stainless steel, cast iron pan
Operating Temperature
-40°C to 70°C
Working Condition
Relative Humidity
10% - 95%
Storage Temperature
-40°C to 70°C
Installation
wall mounted
Size and Weight
Overall Dimension：230╳125╳76 mm
Packet:
310╳175╳115 mm
Weight:2.1 Kg
Protection
Level(Water
proof/Damp proof)
IP65
5.1.2. Basic Feature
 Support G.711,G.729 codec.
 Support SIP 2.0(RFC3261) and related RFC.

Unlock function (swipe or communication)
 Water Proof and Dust Proof;
