AXLES, TIRES, and TRACKS
AXLES,
TIRES, and
TR
ACKS
Liqui
d Fertilizer
Applicator
A10 /
A13 /
A18 /
A24
Page
40
Checking Wh
eel Nuts
A.
Main Frame Wheel Nu
t
B.
Gauge Wheel Nut
Check
tightness
of
all
wheel
nuts
(A)
and
(B)
during
the
first
week
of
operation
and
periodically
after that.
T
ighten all
wheel bolts to
specification
.
Item
Specification
(A) Main Frame
Wheel Nut
359 N-m (265 ft-lbs.)
(B) Gauge Wheel Nu
t
95 N-m (70 ft-lbs.)
39
41
