Feasa 3-F - BusC - Initiate Global Capture

To Next Page

To Previous Page

FEASA LED ANALYSER

FUNCTIONAL VERSION

Daisy Chain Mode

BusC - Initiate Capture for all LED Analyser's

Transmit Receive

busc OK

Description

This command will cause all LED Analysers in the Daisy Chain to initiate a capture sequence

using the Automatic Range Mode. To specify a Range manually see the command BusC# on

the next page.

After the capture cycle use the command BusGet#### to activate a specific LED Analyser.

All the standard commands can then be used to read back the LED Test data.

Example:

The PC transmits busc to instruct all LED Analysers in the Daisy Chain to initiate a Capture

cycle.

busc
