FEASA LED ANALYSER

FUNCTIONAL VERSION

Get Data Mode

getPHOTOPIC - Get which Photopic Mode is active

Transmit Receive

getphotopic 0 or 1 or 2

Where: 0 is Photopic Response OFF

1 is Response Photometric

2 is Response Radiometric

Description

The Led Analyser is shipped from the factory in photopic mode 1. This corrects the Absolute

Intensity to reproduce the photometric response (for lm, mcd). This can be verified by typing

the command getphotopic with the answer 1.

The photopic mode can be set to a radiometric response by sending the command

setphotopic2. This corrects the Absolute Intensity to reproduce the radiometric response (for

mW)

This command is only available on Software Rev F210 upwards
