Feasa 3-F - Reset Sequence Pattern

To Next Page

To Previous Page

FEASA LED ANALYSER

FUNCTIONAL VERSION

Sequence Capture Mode

ResetSequence## - Reset a sequence pattern

Transmit Receive

Resetsequence##

resetsequenceall

Where:

## represents the number of a sequence pattern and is a value in the range 00 - 20.

all represents the all sequence patterns stores in the Analyser. (max 21 patterns)

Description

This command resets the sequence pattern number ##. The pattern is identified by a number

in the range 00 – 20. Up to 21 patterns can be stored.

The sequence pattern ## will be deleted from memory.

Example:

The PC transmits resetsequence01 to the LED Analyser to instruct it to delete sequence

pattern 01.

resetsequence01
