FEASA LED ANALYSER

FUNCTIONAL VERSION

User Calibration Mode

set/putABSINTMULT@@ - Set the Absolute Intensity Multiplier Factor

Transmit Receive

setabsintmult@@m.mmmmme+mm

putabsintmult@@m.mmmmme+mm

Where:

@@ represents the Fiber Number and is a number in the range 01 – 20.

m.mmmmme+mm represents the Absolute Intensity Multiplier Factor

Description

The command setabsintmult@@m.mmmmme+mm directs the LED Analyser to set the

Absolute Intensity Multiplier Factor on Fiber @@ to m.mmmmme+mm

Example:

send the command setabsintmult@@m.mmmmme+mm to the LED Analyser to instruct it

to set the Absolute Intensity Multiplier Factor on Fiber 3 to 1

setabsintmult031.00000e+00
