Manual MWD BP
FEIG ELECTRONIC GmbH Page 25 of 97 MWD BP_Handbuch_mehrsprachig_8.doc
E N G L I S H
2 General
The MWD BP Radar Motion Detector operates with a planar microwave antenna and is used on industrial
gates for entry and access recognition.
The device is intended for installation outdoors and is preset for typical gate applications.
Operation is via two buttons on the case or optionally using an infrared remote control. Thereby, the operator
prompting is done using a 7-Segment display.
The two output relays provided can be adjusted independently from each other in many ways.
The approach sensitivity and the direction logic can be adjusted for both channels of the motion detector.
The detector can also distinguish between people and vehicles and suppress cross-traffic.
3 Technical Data
Case dimensions (W x H x D): 135x65x130 mm
Material
Case and retaining bracket
Cover
ASA
PC
Weight with retaining bracket 160 g
Protection class IP65
Supply voltage 12-27 V AC, 50 – 60 Hz
12-30 V DC, GND must be connected to PE.
SELV, limited capacity power source according to EN 60950-1
Power consumption typical. 1.0W
max. 2.4W
Permissible operating temperature
Storage temperature
Relative humidity
-20 °C to +55 °C
-30 °C to +75 °C
< 95% non-condensing
Frequency 24.125 GHz
Transmission power typical. 40 mW EIRP
max. 100 mW EIRP
Output relay
max. switching voltage
max. switching current
min. switching load
contact type Relay 1
contact type Relay 2
30 V AC/DC
1A for resitive load
1 mA / 5VDC
1 change over contact
1 normally open contact
ATTENTION
The common of the relays is connected
directly to 24V with some Sensor versions, e.g. version –A.
IMPORTANT
An external relay contacts protection circuit
must be provided for inductive load.
Connection cable flexible, max. wire cross section 1.0 mm
2
Cable external diameter 5 – 7 mm
Maximum mounting height 7m
If the device becomes unusable, dispose it in accordance with the current statutory
regulations !
