Manual MWD BP
FEIG ELECTRONIC GmbH Page 38 of 97 MWD BP_Handbuch_mehrsprachig_8.doc
E N G L I S H
P. Setting
range
Function Description / note Factory
setting
r.
0 ... 4 Relay function
This setting assigns the channels 1 and 2 to both available
voltage-free relays. Combinations are also possible.
0: off
1: channel 1 (for channel 1)
2: channel 2 (for channel 2)
3: channel 1 OR channel 2
4: channel 1 AND channel 2
Relay 1 =
1
Relay 2 =
2
o.
0 ... 1 Relay operating
mode
The logical switching behaviour per channel of the relays
can be specified with this parameter.
0: open circuit current principle
1: no-load current principle
0
13 Comfort profiles
Independently of the opened channel, profiles set the parameters for the channel functionality and for the
relay functionality for both channels simultaneously.
P. Setting
range
Function Description / note Factory
setting
P.
0 ... 9 Profiles
Several parameters are set simultaneously to frequently
occurring convenience functions with profiles.
1: factory setting
2 ... 9: parameter profile 2 to 9 (see Chapter 16)
)
If a parameter is subsequently modified so that it is
different from the profile settings, this is indicated by
displaying the value “0”.
1
IMPORTANT
Restoring the parameters to the factory settings is done using the parameter “Profiles” with a
parameter value of “1”. Alternatively, factory settings can be restored by pressing both buttons on
the case when switching on the power supply of the device.
14 List of the service parameters
P. Setting
range
Function Description / note Factory
setting
This parameter specifies the device address for channel 1.
Only odd numbered addresses can be input for channel 1.
The next higher even number is then automatically assigned
to the second channel.
1
Address 13579BD
Channel 1 / Relay 1 1 3 579BD
A.
1, 3, 5, 7,
9,
b, d
Device Address
Channel 2 / Relay 2 2 4 6 8 A C E
