Feig Electronic MWD BP - 8.3 Changing parameters; Parameterisation using remote control

Manual MWD BP
FEIG ELECTRONIC GmbH Page 33 of 97 MWD BP_Handbuch_mehrsprachig_8.doc
E N G L I S H
8.3 Changing parameters
Before changing parameter values you have to open the parameter entry as described in chapter 8.1.
Key
Key-
press
Description Action
Display
Example
1. Right
short
(long)
Change parameter name
(long: quick selection)
Display parameter name with
character and decimal point.
d.
2. Left short
Return to display
actual parameter value
Actual parameter value is
displayed without decimal point.
1
3. Right
short
(long)
Change parameter value
(long: quick selection)
Display changed parameter value
with blinking decimal point.
2.Ò
4a. Left short
Undo changes
Display actual parameter value
again (without decimal point).
1
or
4b. Left long
Save new parameter value
Decimal point expires after
successful saving.
2
5. Left short
Return to display
parameter name
Display parameter name with
character and decimal point.
d.
8.4 Opening service parameters
To display the Service Parameter you have first to open the parameter entry as described in chapter 8.1.
Service Parameter names are displayed with flashing character and static decimal point.
Menu navigation is conform to the navigation of standard parameter.
Button
Key-
press
Description Action
Display
Example
1. Left and Right long
Activate service parameter from
standard parameter menu
Display first service parameter
name
ÑA.
9 Parameterisation using remote control
When starting parameter mode, the channel to be edited or parameterised must first be selected.
The numeric address of the first channel is displayed flashing when parameter mode is started. The following
number is automatically assigned to channel 2.
The channel for editing is opened by confirming the device address.
The value “1” is usually displayed for channel 1. If 1 is now input, channel 1 is processed and if 2 is input,
then channel 2 is processed.
