TST Startup FU3E
FEIG ELECTRONIC GmbH Page 13 of 29 FU3E_Inbetriebnahme_7_GB.doc
6 Basic Settings
To set the TST FU3E door controller into service, please follow the steps below.
6.1 Automatic querying of the basic data
If the TST FU3E door controller has not been preconfigured by the door manufacturer, the following
parameters are automatically queried:
IMPORTANT
For the TST FU3E door controller to automatically query the parameters, DIP switch
must be turned on (DIP switch location see Fig. 15: Position DIP-switch).
) If DIP switch is not turned on and the basic parameters not set, error code F.090 is displayed..
)A „-1“ in the display is used by the controller as an indication that querying of this parameter is being
forced.
• Positioning system P.205
The limit switch system in use must be set using Parameter P.205.
P.205: 0 = Mechanical limit switches Version 1 (Fig. 9: Connecting cam switches)
P.205: 1 = Mechanical limit switches Version 2 (limit switches and pre-limit switches are normally closed)
P.205: 2 = Incremental encoder as limit switch
P.205: 3 = Absolute encoder DES-A
P.205: 4 = Absolute encoder TST PB-A
P.205: 5 = SSI encoder (only with UL-Version)
P.205: 6 = reserved
P.205: 7 = Absolute encoder DES-B
P.205: 8 = Absolute encoder TST PD
• Reference switch profile P.25F
If an incremental encoder is used as a limit switch, you must use Parameter P.25F to define a reference
switch type and the behavior of the controller after power-up.
P.25F: 0 = The lower end position must be moved to and saved.
P.25F: 1 = After power-up the system automatically synchronizes to a lower reference switch.
P.25F: 2 = After power-up the system automatically synchronizes to the safety edge.
P.25F: 3 = After power-up the system automatically synchronizes to an upper reference switch.
P.25F: 4 = After power-up the system automatically synchronizes to an upper mechanical stop.
P.25F: 5 = After power-up the system automatically synchronizes to the safety edge and then to an
upper mechanical stop.
P.25F: 6 = After power-up the system automatically synchronizes to the safety edge and then to an
upper reference switch.
P.25F: 7 = After power-up the system automatically synchronizes to an upper reference switch and then
to an upper mechanical stop.
