12 Message Overview
Faults can be aknowledged provided they are not reset automatically.
WARNING
The cause of the fault must be resolved first before the corresponding message is
acknowledged.
For this, you press the Å STOP button and keep it pressed and press the EMERGENCY STOP button
afterwards. Alternatively, the Å STOP button can also be kept pressed for approx. 5 seconds.
Improper end positions
F.000
Door position too far up
• Too small a parameter value for upper emergency limit
switch
• Upper limit switch range (limit switch band) too small
• Mechanical brake defective or improperly set
F.005
Door position too far down
• Too small a parameter value for lower emergency limit
switch
• Lower limit switch range (limit switch band) too small
• Mechanical brake defective or improperly set
Implausibilities in door movement
F.020
Run time exceeded (during
opening, closing or deadman)
• current motor run time has exceeded set maximum run time,
door may be sticking or is blocked
• If using mechanical limit switches, one may not have tripped
F.030
Lag error (position change of
the door is less than expected)
• Door or motor is blocked
• Too little power for lift torque
• To little speed
• Mechanical limit switch was not left or is defective
• Absolute or incremental encoder not tightened sufficiently in
its mounting
• Wrong positioning system selected (P.205)
F.031
Detected rotational direction
deviates from expected
• When using incremental encoders: Channel A and B
reversed
• Motor rotation direction reversed compared with calibration
setting
• Too much „pancaking“ when starting, brake releases too
soon, or too little torque, adjust boost as necessary.
F.043
Pre-limit switch fault (light
barrier)
• The pre-limit switch for the light barrier remains activated
even in the middle end position or upper end position.
Error messages for incremental encoder
F.050
Reference switch position
deviates from permissible
range.
During cyclical synchronization
• Reference switch constantly tripped (defective)
• Reference switch trips too far from the selected reference.
• Reference switch trips in the limit switch band
• P270 and P280 are both at the reference switch
F.051
Reference switch position
deviates from permissible
range.
• Reference switch lies in the limit switch band
• Reference switch is beyond 15% EO
• Reference switch defective
F.052
Reference switch not
recognized
• The reference switch is not recognized within 20% EO
during automatic synchronization after power-on
• The reference switch is not recognized in the associated end
position.
Maintenance counter exceeded
F.080
Fault: Maintenance is required
• Service counter has expired
