TST Startup FU3E
FEIG ELECTRONIC GmbH Page 17 of 29 FU3E_Inbetriebnahme_7_GB.doc
8 Additional connection possibilities
8.1 Photo eye
+24V
Photo eye
GND
8
911
10 12
13 15
14 16
17 19
18 20
21 23
22 24
25 27
26 28
29 31
30 32
X18 X17
Fig. 16: Photo eye connection
8.2 External triggering devices
CLOSE
OPEN
STOP
External
triggering device
X13
X20
X14
Si2
12V
Si1
S1a S2a
S1b S2b
13
24
57
68
911
10 12
13 15
14 16
Fig. 17: External triggering devices
9 Overview of outputs
29 31
30 32
41
42
43 45
44 46
51 54
53 53
T2
X4
T1
T3
K4: Door is OPEN
K5: Door is CLOSE
K3: Break
